Installation Steps
Prepare Your Rod Holder
Choose a rod holder with an inner diameter between 1" and 1.5" (25-38mm). Ensure the rod holder is clean and free of debris or fishing line.
Tip: Choose a rod holder that's positioned away from the boat's edge and has clear sight lines for throwing clays.
Insert the Mount
Hold ReelTrigger with the base pointing down. Slide the mounting post into your rod holder at a slight angle (approximately 45°).
Insert at angle
Lock in Place
Push down firmly until the quick-release mechanism clicks and locks. The unit should feel secure with no wobble. Pull up gently to confirm it's locked.
Check: Give it a firm tug to ensure the mount is secure before use.
Attach the Throwing Arm
Slide the throwing arm into the receiver on top of the unit. Rotate until the alignment holes match, then insert the locking pin.
Adjust Settings
Set your desired throw distance by turning the distance dial. Position the throwing arm to your preferred angle using the rotation knob.
Distance Dial
Turn clockwise for longer throws, counter-clockwise for shorter throws. Range: 10m - 60m.
Rotation Knob
Loosen to rotate arm 180°, tighten to lock position.
You're Ready to Shoot!
Lift the throwing arm, place a clay target on the spring-loaded cup, and push down until it clicks. Pull the trigger to launch!
First Time?
Start with the shortest distance setting and work your way up as you get comfortable with the throwing arc.
